TREK Madone SL 5 Gen 8 (2027)
TREK Madone SL 5 Gen 8 (2027) - Image 2
TREK Madone SL 5 Gen 8 (2027) - Image 3

TREK Madone SL 5 Gen 8 (2027)

Original price was: R60 000.00.Current price is: R55 000.00.

The Madone SL 5 Gen 8 is a lightweight aero road bike that brings elite racing tech to a lower price point. It offers similar aero benefits to the pricier Madone SLR Gen 8 models, but with a more economical OCLV 500 Carbon lay-up and two-piece cockpit with hidden cable routing. A Shimano 105 group set, alloy handlebars and alloy wheels keeps the price down while still delivering clean mechanical shifting you can trust.

SKU: BLK - ML,XL / LAVENDER - ML,L,XL / WHITE - L Categories: , ,

Description

Frame
500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142×12 mm thru axle
*Fork

Size: XS, S, M, ML, L, XL

Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12×100 mm chamfered thru axle

Size: XS, S, M, ML, L, XL

Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle

Weight
ML – 8.64 kg / 19.05 lbs (with tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).

Shifter
Shimano 105 R7120, 12-speed
Front derailleur
Shimano 105 R7100, braze-on, down swing
Rear derailleur
Shimano 105 R7100, 36T max cog
*Crank

Size: XS, S

Shimano 105 R7100, 50/34, 165 mm length

Size: M, ML

Shimano 105 R7100, 50/34, 170 mm length

Size: L, XL

Shimano 105 R7100, 50/34, 172.5 mm length
Bottom bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano 105 7101, 11-34, 12-speed
Chain
Shimano SLX M7100, 12-speed
Max. chainring size
1x: 54T, 2x: 56/43

Hub front
Bontrager alloy, sealed bearing, CentreLock disc, 100×12 mm thru axle
Skewer front
Bontrager Switch chamfered thru axle
Hub rear
Bontrager alloy, sealed bearing, CentreLock disc, Shimano 11-speed freehub, 142×12 mm thru axle
Skewer rear
Bontrager Switch chamfered thru axle, removable lever
Rim
Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve
Tyre
Bontrager Aeolus Pro, Tubeless Ready, aramid bead, 120 tpi, 700×28 mm
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Max tyre size
32 mm (as measured, see manual for details)

Saddle
Bontrager Aeolus Elite, austenite rails, 145 mm width
Seatpost
Madone aero carbon seat post, 0 mm offset, short length
*Handlebar

Size: XS

Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width

Size: S, M

Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width

Size: ML, L

Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width

Size: XL

Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Handlebar tape
Trek EcoTack
*Stem
Size: XS
Trek RCS Pro, -7-degree, 80 mm length
Size: S, M
Trek RCS Pro, -7-degree, 90 mm length
Size: ML, L
Trek RCS Pro, -7-degree, 100 mm length
Size: XL
Trek RCS Pro, -7-degree, 110 mm length
Brake
Shimano 105 hydraulic disc, flat mount
Brake rotor
Shimano CL700, CentreLock, 160 mm
Rotor size
Max brake rotor sizes: 180 mm front, 160 mm rear

Additional information

COLOR:

BLACK, LAVENDER, WHITE, CHRISTAL WHITE
SIZE:

XS, S, M, ML, L, XL
