Description
Specifications
FRAME: NINETY-SIX LITE V
- 110mm suspension travel
- material: aluminium
- 29×2.5″ max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
COLOR: GLITTER CHERRY
FORK: SR Suntour Raidon34 R-2CR
- Air
- 120mm suspension travel
- Tapered
- Remote lockout
- 46mm fork offset
- 29×2.4″ max wheelsize
SHOCK: SR Suntour Edge LOR
- lockout
BRAKES: Shimano MT200
- 2 piston
ROTORS: Shimano RT10
- 180mm
HEADSET: Acros ICR MERIDA EXTERNAL neck
- Upper and lower IPS sealing
HANDLEBAR: MERIDA EXPERT CC
HANDLEBAR STEM: MERIDA TEAM CC III
GRIP: MERIDA COMP EC
DERAILLEUR REAR: Shimano Deore M6100
- SGS
SHIFTERS: Shimano Deore M6100
SEAT POST: MERIDA EXPERT TR II
- 34.9mm diameter
- 0mm setback
- travel seatpost XSHORT/SHORT: 150mm, MID: 170mm, LONG, XLONG: 200mm
SEAT CLAMP: MERIDA EXPERT
SADDLE: MERIDA COMP SL
- 25% recycled material
- V-mount
CHAIN: KMC X12
CRANK: Shimano Deore MT512
- 32 teeth
- 170 mm for all sizes
FREEWHEEL: Shimano Deore M6100
- 10-51 teeth
- 12 speed
BOTTOM BRACKET: Shimano BB-MT-501
- 24mm
HUBS: Shimano TC500-B / Shimano TC500-MS-B
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
RIM: MERIDA COMP CC II
- 25mm inner width
- material: aluminium
- tubeless ready
TYRE FRONT: Maxxis Rekon Race
- 29×2.4″
- wire
TYRE REAR: Maxxis Rekon Race
- 29×2.4″
- wire
AXLES: MERIDA EXPERT TR
- including removeable lever, 6/4mm allen key
SPOKES: Black stainless w/ black nipples
SPOKES: disc attached
MAX WEIGHT: 135 kg
