FRAME: eONE-SIXTY SL CF4 I
- material: carbon
- 160mm suspension travel
- 29×2,4″ max. wheelsize
- 148x12mm axle standard
- fixed battery
COLOR: GUNMETAL GREY (BLACK)
FORK: Marzocchi Z1 eMTB
- Air
- 160mm suspension travel
- Tapered
- 44mm fork offset
- 29×2.6″ max wheelsize
SHOCK: Marzocchi Bomber Air
- platform
BRAKES: Shimano Deore
- 4 piston
ROTORS: Shimano RT64, 203mm
HEADSET: Acros ICR MERIDA INTEGRATED neck w/ Blocklock
HANDLEBAR: MERIDA EXPERT eTR
HANDLEBAR STEM: MERIDA EXPERT eTR II
GRIP: MERIDA EXPERT EC
DERAILLEUR REAR: Shimano Deore
SHIFTER: Shimano SL -MT500-IL / Shimano Deore
SEAT POST: MERIDA COMP TR III
- 34.9mm diameter
- 0mm setback *
SEAT CLAMP: MERIDA EXPERT
SADDLE: MERIDA COMP SL
- V-mount
- incl. MERIDA minitool
PEDAL: VP 532
CHAIN: Shimano Deore M6100
CHAINWEEL: FSA 1x Alloy Spider + Mega Tooth steel chain ring
- 34 teeth
CRANK: FSA CK-220 wide E-Bike Forged Crankset
- 165mm for all sizes
FREEWHEEL: Shimano Deore
- 10-51 teeth
- 12 speed
HUBS: Shimano TC500
- 15x100mm width front hub
- 32 spoke holes
- Centerlock
- 12x148mm width rear hub
- 32 spoke holes
- Centerlock
RIM: Reynolds 309 Enduro Comp
- 30mm inner width
- material: aluminium
- Tubeless ready (tubeless tape installed)
- 29″
TYRE FRONT: Maxxis Assegai
- 29×2.5 “
- fold
- TR EXO+ 3C MaxxGrip
TYRE REAR: Maxxis Minion DHR II
- 29×2.4 “
- fold
- TR EXO+ 3C MaxxTerra
AXLES: MERIDA EXPERT TR
- including removeable lever, 6/4mm allen key
SPOKES: Black stainless
- black nipples
LIGHT FRONT: USB rechargable Chance Good CG-119PG-BLACK(1)
LIGHT REAR: USB rechargable Chance Good CG-404RG-BLK
FENDER: RF-001 mini fender
DRIVE UNIT: Bosch Performance Line SX
BATTERY: Bosch CompactTube
- 400Wh
display Bosch Kiox 400C
APPROX: weight 20.9 kg
weighed at frame size M
MAX WEIGHT: 140 kg
