Description
FRAME: BIG.TRAIL TFS II
- material: aluminium
- 29×2.4″ max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
COLOR: MOKKA (BROWN)
- Color: glossy mokka TA-3096
FORK: Rock Shox Psylo Silver RC
- Air
- 140mm suspension travel
- platform
BRAKES: Shimano MT410
- 4 piston
- 2 piston
ROTORS: Shimano RT30
- 203mm
- 180mm
HEADSET: Acros ICR MERIDA EXTERNAL neck
- Upper and lower IPS sealing
HANDLEBAR: MERIDA COMP TR
HANDLEBAR STEM: MERIDA EXPERT eTRII
GRIP: MERIDA COMP EC
DERAILLEUR REAR: Shimano CUES U6000
- GS
SHIFTERS: Shimano SL-MT500-L / Shimano CUES U6000
SEAT POST: MERIDA EXPERT TR II
- 34.9mm diameter
- 0mm setback
- XSHORT: 150mm travel seatpost : SHORT : 170mm travel seatpost : MID/LONG: 200mm travel seatpost : XLONG: 230mm travel seatpost
SEAT CLAMP: MERIDA EXPERT
SADDLE: MERIDA COMP SL
- 25% recycled material
- V-mount
CHAIN: KMC xGlide
CRANK: MERIDA Expert TR II
- 32 teeth
- 165mm XSHORT and SHORT
FREEWHEEL: Shimano LG300
- 11-48 teeth
- 10 speed
HUBS: Shimano TC500-B / Shimano TC500-HM-B
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
RIM: MERIDA COMP TR
- 29mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
TYRE FRONT: Maxxis Minion DHF
- 29×2.5″
- fold
- TR EXO Dual
TYRE REAR: Maxxis Dissector
- 29×2.4″
- fold
- TR EXO Dual
AXLES: MERIDA COMP TR
- including removeable lever, 6/4mm allen key
SPOKES: Double Butted Black stainless
APPROX WEIGHT: 13.9 kg
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
MAX WEIGHT: 135 kg
