FRAME: BIG.NINE TR LITE III
- material: aluminium
- 29×2.4″ max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
FORK: SR Suntour Raidon 34 2CR
- Air
- 120mm suspension travel
- Tapered
- platform
- 46 mm fork offset
BRAKES: Shimano MT200
- 2 piston
ROTORS: Shimano RT10
- 180mm
HEADSET: Acros ICR MERIDA EXTERNAL neck
- Upper and lower IPS sealing
HANDLEBAR: MERIDA EXPERT CC
HANDLEBAR STEM: MERIDA TEAM CC III
GRIP: MERIDA COMP EC
DERAILLEUR REAR: Shimano CUES U6000
- GS
SHIFTERS: Shimano CUES U6000
SEAT POST: MERIDA COMP TR
- 30.9mm diameter
- 0mm setback
- S: 125mm travel seatpost : M/L: 150mm travel seatpost : XL/XXL 175mm travel seatpost
SEAT CLAMP: MERIDA EXPERT
SADDLE: MERIDA COMP SL
- 25% recycled material
- V-mount
CHAIN: KMC xGlide
CRANK: MERIDA Expert TR II
- 32 teeth
- 170 mm (S), 175 mm-M up
FREEWHEEL: Shimano LG400
- 11-50 teeth
- 11 speed
BOTTOM BRACKET: Samox BSA 24mm EB2401
HUBS: Shimano TC500-B / Shimano TC500-HM-B
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
RIM: MERIDA COMP CC II
- 25mm inner width
- material: aluminium
- tubeless ready
TYRE FRONT: Maxxis Rekon
- 29×2.4″
- wire
TYRE REAR: Maxxis Rekon
- 29×2.4″
- wire
AXLES: MERIDA COMP TR
- including removeable lever, 6/4mm allen key
SPOKES: Black stainless
MAX WEIGHT: 135 kg
